Specifications
01 MEASURING RANGE
- ACCURACY: WITH PRISM: 2MM + 2PPM, WITHOUTT PRISM 3MM + PPM
- ATMOSPHERIC CORRECTION: AUTOMATIC CORRECTION BY IMPUTTING PARAMETER
- DIGITAL DISPLAY: MAXIMUM: 99999999.9999 MINIMUM: 0.1 MM
- MEASUREMENT RANGE: 3 PRISM: 8000 - 10000 M
- MEASUREMENT RANGE: 1 PRISM: 5000M
- MEASURING TIME: TRACKING 0.1S. FINE 0.3S (OPIONAL)
- NON PRISM: 1000M
- PRISM CONTENT: AUTOMATIC CORRECTION BY INPUTTING PARAMETER
02 ANGLE MEASUREMENT
- ACCURACY : 2
- DETECTION METHOD: HORIZONNTAL: FOUR SENSORS
- DETECTION METHOD: VERTICAL: FOUR SENSORS
- DIAMETER OF THE RASTER DISC: 79 MM
- MEASUREMENT METHOD : ABSOLUTE ENCODING
- MINIMUM READING: 1
03 TELESCOPE
- EFFECTIVE APERATURE: 45 MM (DTM 50 MM)
- FIELD OF VIEW: 1
- IMAGE : ERECT
- LENGTH: 154 MM
- MAGNIFICATION: 30 X
- MINIMUM FOCUS: 1 M
- RESOLVING POWER: 3
04 COMPENSATION
- LASER PLUMMET`: YES
- RESOLVING POWER: 1
- SENSITIVITY OF VIALS: CIRCULAR VIAL: 8' / 2 MM
- SENTIVITY OF VIALS: PALTE VIAL: 30
- SYSTEM : DUAL AXIS LIQUID-ELECTRIC
- WORKING RANGE: ±3 '
05 DATA STORAGE AND COMMUNICATION
- COMMUNICATION PORT: RS-232, MINI USB
- EXTERNAL MEMORY: SD CARD (UP TO 32 GB)
- INTERNAL MEMORY: 4M / 40000 POINTS
06 DISPLAY
- BATTERY : POWER SUPPLY: RECHARGEABLE BATTERY (3100 MAH)
- BATTERY: VOLTAGE: 7.4V DC
- BATTERY: OPERATION TIME: 10 HOURS
- TYPE : DUAL SIDES, 6 LINES, BLACK AND WHITE
07 DIMENSIONS AND WEIGHT
- DIMENSION: DIMENSIONS AND WEIGHT: 160 MM X 150 MM X 330 MM
- WEIGHT: 5.7 KG
08 ENVIRONMENTAL SPECIFICATION
- DUST / WATER (IEC60529): IP66
- HUMIDITY: 95%, NON - CONDENSING
- WORKING TEMPERATURE RANGE: - 20° C ~ 50° C
